& & Main Specifications
Keyboard
Keyboard
88 keys (PHA III Ivory Feel Keyboard with Escapement)
Touch Sensitivity
Key Touch: 100 types, Fixed Touch
Hammer Response: Off, 10 levels
Keyboard Modes
Whole
Dual (volume balance adjustable)
Split (split point adjustable)
Twin Piano
Pedals
Pedals
Damper (Progressive Damper Action Pedal, capable of
continuous detection)
Soft (capable of continuous detection)
Sostenuto (function assignable)
Sound Generator
Piano Sound
SuperNATURAL Piano Sound
Sound Generator Conforms to GM2/GS/XG Lite
Max . Polyphony 128 voices
Tones
Grand Piano: 10 tones
Early Piano: 6 tones
E. Piano: 10 tones
Strings: 14 tones
Other: 307 tones (including 8 drum sets, 1 SFX set)
Temperaments 8 types, selectable temperament key
Stretched Tuning
Preset, User tuning (adjustable in individual notes: -50.0–+50.0
cent), Off
Master Tuning 415.3 Hz–466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose
Key Transpose: -6–+5 (in semitones)
Playback Transpose: -6–+5 (in semitones)
Effects
Ambience (Off, 10 levels)
Brilliance (Off, -10–0–+10)
Only for Piano Tones (Piano Designer):
Open/close lid (7 levels)
Soundboard Behavior (Off, 10 levels)
Cabinet Resonance (Off, 10 levels)
Hammer Noise (5 levels)
Damper Noise (Off, 10 levels)
Duplex Scale (Off, 10 levels)
Damper Resonance (Off, 10 levels)
String Resonance (Off, 10 levels)
Key Off Resonance (Off, 10 levels)
Only for Organ Tones:
Rotary Speaker Effect (Slow/Fast)
Metronome
Tempo
Quarter note = 10 to 500
Beat 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8
Volume 11 levels
SMF Recorder
Tracks
3 tracks
Song Save Format Standard MIDI Files (Format 0)
Songs
Recorder section: 1 song
Internal Memory: Max. 99 songs
Note Storage Approx. 30,000 notes
Controls
Song Select, Play/Stop, Rec, Rewinding, Fast-forwarding, Previ-
ous song, Next song, Part Mute, Mute Volume, Tempo, Tempo
Mute, All Songs Play, Count-in, Song Balance, AB Repeat
Tempo Quarter note= 10 to 500
Resolution 120 ticks per quarter note
Audio/Audio CDs
Playback
File Format: Audio File (WAV 44.1 kHz/16-bit linear format)
Audio CDs (CD-DA) (when using optional CD drive)
Recording
(with Keyboard, SMF data, Audio from Input jacks)
File Format: Audio File (WAV 44.1 kHz/16-bit linear format)
Transpose
Playback Transpose (with Audio from Input jacks):
-6–+5 (in semitones)
Tempo Audio Playback Speed: 75–125 %
Controls
Song Select, Play/Stop, Rec, Rewinding, Fast-forwarding,
Previous song, Next song, Tempo, All Songs Play, Song Balance,
AB Repeat, Center Cancel (with Audio from Input jacks)
Internal Memory
Song Save Format
Standard MIDI Files (Format 0)
Songs Max. 99 songs
External Memory
External Storage
USB Flash Memory
Playable Song Format
Standard MIDI Files (Format 0/1)
Roland Original Format (i-Format)
Audio File (WAV 44.1 kHz/16-bit linear format)
Audio CDs (CD-DA) (when using optional CD drive)
Song Save Format
Standard MIDI Files (Format 0)
Audio File (WAV 44.1 kHz/16-bit linear format)
Other
Internal Songs
Piano Masterpieces: 75 songs
Selections: 10 songs or greater
Czerny #100: 100 songs
Hanon: 20 songs
Rated Power Output
60 W x 2
10 W x 2
Volume Level (SPL)
110 dB
* This figure was measured according to the method that is
based on Roland’s technical standard.
Speakers
Cabinet Speakers: 16 cm x 2 (with Speaker box)
Nearfield Speakers: 5 cm x 2
Spatial Speakers: (12 x 8 cm) x 2
Display Graphic monochrome LCD 122 x 32 dots
Language English
Control Volume (Slider)
Other Functions
Panel Lock
MIDI Visual Control
Connectors
AC inlet
Pedal connector
Input jacks (L/Mono, R): RCA phono type
Output jacks (L/Mono, R): 1/4-inch phone type
USB COMPUTER port
USB MEMORY port
MIDI connectors (In, Out)
Phones jack (Stereo, with Twin Piano Individual Mode) x 2:
Stereo 1/4-inch phone type
Power Consumption
34 W (31 W to 85 W)
34 W: Average power consumption while piano is played
with volume at center position
31 W: Power consumption immediately after power-up;
nothing being played
85 W: Rated power consumption
Dimensions
(including piano stand)
(With Music Rest)
1,405 (W) x 498 (D) x 1,129 (H) mm
55-3/8 (W) x 19-5/8 (D) x 44-1/2 (H) inches
(When folding down the Music Rest)
1,405 (W) x 498 (D) x 956 (H) mm
55-3/8 (W) x 19-5/8 (D) x 37-11/16 (H) inches
Weight
(including piano stand)
HP507-RW, HP507-SB: 80.5 kg/177 lbs 8 oz
HP507-PE: 82.5 kg/181 lbs 15 oz
Accessories
Owner’s Manual
Roland 60 Classical Piano Masterpieces
Power Cord
Headphone Hook (*1)
*1 Supplied with the stand.
Options
(sold separately)
USB Flash Memory (*2)
USB CD Drive (CD-01A)
*2 Use USB Flash memory sold by Roland. We cannot guarantee
operation if other products are used.
* In the interest of product improvement, the specifications and/
or appearance of this unit are subject to change without prior
notice.
Roland HP507: Digital Piano
