Raising the music rest

Gently raise the music rest .

Fold down the latches to secure the music rest .

Folding down the music rest

While using one hand to support the music rest, raise the

latches located on the back of the music rest, then gently

fold down the music rest .

Using the music holders

You can use the holders to hold pages in place.
When not using the holders, leave them folded down.

Push

Before You Play

* When opening/closing the lid or raising/folding down the music rest, please be careful not to get your fingers pinched between the movable part

and the panel. In places where small children are present, make sure that an adult provides supervision and guidance.

Setting Up the Music Rest

Opening/Closing the Lid

To open the lid, use both hands to lift it lightly, and slide it away

from yourself.
To close the lid, pull it gently toward yourself, and lower it softly

after it has been fully extended.

NOTE

When opening and closing the lid, be careful not to let your

fingers get caught. If small children will be using the HP507,

adult supervision should be provided.
If you need to move the piano, make sure the lid is closed first to

prevent accidents.

Using the lid to conceal the buttons and display

(Classic Position)

You can use the lid to conceal the buttons and the display. This

allows you to concentrate on performing without being distracted

by the buttons or the display.

Lid

Installing the CD Drive (Sold separately)

Attach the CD drive as shown the figure, using the mounting holes on the HP507’s

bottom panel.

* For details of the attachment or connecting, refer to the owner’s manual of the CD

drive.

* Use a CD drive sold by Roland. We cannot guarantee operation if any other CD drive

is used.

NOTE

• You cannot play back CD-R/RW disks to which audio tracks have been added or CDs

containing both audio tracks and data (CD Extra).

• The HP507 is capable of playing back only commercial CDs that conform the official standards-those that carry the “COMPACT DISC

DIGITAL AUDIO” logo.

• The usability and sound quality of audio discs that incorporate copyright protection technology and other non-standard CDs cannot be

guaranteed.

• For more detailed information on audio discs featuring copyright protection technology and other non-standard CDs, please consult the

disc vendor.

• You cannot save songs and styles to CDs, and you cannot delete songs or styles recorded to CDs. Furthermore, you cannot format CDs.
