41 Raymarine Sirius Weather System Installation Guide
Appendix A: Technical specifications
SR100 Technical Specification
General
Environmental:
Waterproof
Operating range
Storage range
Humidity
IPX 2
10
o
C to + 50
o
C
20
o
C to + 70
o
C
up to 95% at 35
o
C non condensing
Receiver
Size
10¾”x 7½” x 2½” (273.3 x 187.2 x 61.7 mm)
Weight
2.2 lbs (1 kg)
Mounting
Four keyholed mounting tabs, screws
Power
Voltage
Current
Fuse
Reverse polarity protected
9 V to 32 V DC
0.7 A at 9 V (2 A peak)
2A (recommended)
Connectors
RJ 45 SeaTalk
hs
3 pin Power
4 pin Audio (not used)
SMB RF Antenna
Antenna
Size
Φ
3½” x 4¼”(including mounting flange and
gasket)
Weight
8 oz. (226 g)
Mounting
Three countersunk holes, screws
Connector
SMB RF
