20
Maintenance and troubleshooting
Introduction
This section provides information on routine maintenance and trouble
shooting that can be carried out by the user.
Maintenance
CAUTION: Power supply
Always turn your weather system OFF before carrying out
routine maintenance.
Your SR50/SR100 Sirius weather unit is a sealed unit!
DO NOT
remove the
cover of the receiver. Adjustments require specialized service procedures
and tools only available to qualified service technicians. There are no user
serviceable parts or adjustments.
Routine checks
Routine checks are limited to the following periodical checks:
• Examine the cables for signs of damage, such as chafing, cuts, or nicks.
• Check that the cable connectors are firmly attached and dust caps are
fitted to any connection not in use.
Cleaning
If you find it necessary to clean the unit, follow these basic procedures:
• Wipe the module clean with a damp cloth.
• If necessary, use iso propyl alcohol (IPA) or a mild detergent solution to
remove any grease marks.
Troubleshooting
Your Raymarine product, prior to packing and shipping, has been subjected
to comprehensive test and quality assurance programs. However, if the
unit should develop a fault, please refer to the following section to identify
the most likely cause and the corrective action required to restore normal
operation. If you still have a problem after referring to the following
section, contact your local dealer, national distributor or Raymarine Tech
nical Services Department for further advice.
Status LED
The LED on the connector panel provides valuable information on the
status of your Sirius Weather system.
The LED blinks green while the system is operating normally. If the unit
detects a problem, the LED blinks amber to indicate a warning or red to
indicate an error. The pattern of the LED blink is a code representing the
nature of the problem. For multiple warnings/errors the codes are given in
sequence with a 1.5 second pause between the indications.
The following table shows the LED status codes and their meanings:
LED color
LED pattern
Description
Green
Blinking
Normal operation
Amber
1sec ON, 2 sec. OFF
Antenna disconnected
Amber
1 sec. ON, 1 sec. OFF, 1 sec.
ON, 2 sec. OFF
SeaTalk
hs
cable
disconnected
