28
2. Press trackpad
Up/Down
to highlight Weather Setup Menu.
3. Press trackpad
Right
. The Weather Setup Menu appears.
4. Press trackpad
Up/Down
to highlight Wind Symbol.
5. Press trackpad
Right
. The Wind Symbol options of barbs or arrows
appear.
6. Press trackpad
Up/Down
to select Wind Symbol style.
7. Press trackpad
Up/Down
to highlight Marine Watchbox Alerts.(These
are the automatic watchboxes).
8. Press trackpad
Right
. The Watchbox alert area options appear.
The options are OFF, 50,150,300, 500 and All. The figures represent the
range from your boat and are dependant on your system settings.
9. Press trackpad
Up/Down
to highlight the selected range.
10. Press
OK
. The Weather Setup Menu closes.
You now need to configure Marine Zones and Watchbox Graphic Display as
Show/Hide.
The default for these is SHOW.
To configure marine zones and watchboxes:
1. Press Presentation. The Marine Zones and Watchbox soft keys appear.
2. Toggle the Watchbox softkey to ON or OFF as required.
3. Toggle the Marine Zones soft key to HIDE or SHOW as required.
4. Press
OK
to accept your choice and return to the top level soft keys.
Specify the information displayed
You need to specify the weather reports or graphics that are shown in the
weather application using the Weather Setup Menu.
To set up reports and graphics:
1. Open a weather application window.
2. Press Display Graphics. The Weather Graphics menu appears.
3. Press the trackpad
Up/Down
to highlight the required menu item.
4. Press the trackpad
Right
to select the item.
5. Press the trackpad
Up/Down
to toggle the item ON or OFF.
6. Press
OK
to accept the options.
7. Repeat Steps 1 through 6 until all required options are specified.
Setup
Weather Setup Menu...
GPS Setup...
Compass Setup...
Weather Setup Menu
Sirius Weather User ID
Wind Symbol
Arrow
Marine Watchbox Alerts
150nm
Storm
Cast OFF
Sea
Surface
Temp OFF
Canadian
Radar
OFF
Storm
Tracks
OFF
Lightning
OFF
Surface
Ob
Stations
OFF
Cities
OFF
Wind
OFF
Waves
OFF
Surface
Pressure
OFF
Weather Graphics
NOWRad
ON
