14
System connections
This section deals with connecting your SR50/SR100 Sirius weather system after installation.
Typical Sirius weather systems are shown in the following illustrations.
SR50
SR100
C-Series Display
Antenna
Weather Receiver
Amplifier
SR50
D9939-1
Power Supply
RANGE
CANCEL
OK
PAGE
ACTIVE
WPTS/
MOB
MENU
DATA
IN
OUT
Power Supply
CANCEL
OK
RANGE
IN
OUT
PAGE
ACTIVE
WPTS
MOB
MENU
DATA
Antenna
Weather Receiver
SeaTalk
hs
Network Switch
E-Series Display
D9075_1
Other SeaTalk
hs
devices
