35 Raymarine Sirius Weather System Installation Guide
Wind
This option shows the current wind direction and strength and can be
displayed as either an arrow or a wind barb. Wind arrows indicate speed
the larger the arrow, the greater (stronger) the wind speed. Wind barbs
give a more precise indication of wind speed as shown on the illustration
below:
Waves
The waves option shows current wave
height in up to 16 shades of color:
•Reds Highest waves
•Greens Intermediate waves.
Blues Lowest waves
3-7 kts 8-12 kts 13-17 kts 18-22 kts 23-27 kts 28-32 kts
33-37 kts 38-42 kts 43-47 kts 48-52 kts 53-57 kts
78-82 kts 73-77 kts 68-72 kts
63-67 kts 58-62 kts
88-92 kts 83-87 kts 98-102 kts 93-97 kts
D9962
