Regency ® L676 Direct Vent Gas Fireplace 43
MAINTENANCE
MAINTENANCE
1) Remove the exterior brick panels.
2) Remove the glass door.
4) Lift up and pull out the heat shield slightly
to clear the screwheads and then hang it
on the top bracket (located directly above
the heat shield).
5) Unplug the power source.
6) Loosen the bottom screw and remove the
top screw from the power module.
7) Pull out the power module.
8) Remove the power module cover by
removing the 2 screws, one on each side.
9) Replace the 9V battery and the AA battery.
3) Loosen the 2 screws that hold the left side
heat shield in place.
BACK-UP BATTERY REPLACEMENT
(within Power Module)
Power Module
Power
Module
a. Release the 2 door latches on the left
and right side at the top of the fi rebox.
b. Swing the door out from the top and release
the hinges on the left and right side of the
door by lifting them up.
Hinge
Door
Latch
Latch Location
Heat
Shield
Bracket
Heat
Shield
10) Reverse steps to re-install.
NOTE: The 9V battery operates the rear burner
under power outage conditions.
The AA battery operates the DC
Sparker for lighting the pilot.
