22
Quick Start
■ STATUS Buttons
The STATUS buttons control MUTE/SOLO/REC/PLAY/AUTOMIX for each tracks. The current
status is shown by the button indicator.
When STATUS MODE is MUTE
During playback/recording: Un-mute (dark)/Mute (orange)
Other: Un-mute (dark)/Archive (red)/Mute (orange)
Blinking orange indicates muted by solo.
Archive: Silence and suppress the processing of a track. Archived tracks are not
loaded into RAM, so they can’t be unmuted in real time. Use the archive command
to reduce the demand on your CPU.
When STATUS MODE is SOLO
Un-solo (dark)
Solo (green)
Blinking green indicates silent by mute.
When STATUS MODE is REC/PLAY
Normal (dark)
Arm for recording (red)
Arm: Enable a track for recording.
When STATUS MODE is AUTOMIX
Normal (dark)
Arm for automation (red)
Blinking red indicates can’t become automation-armed, because there is at least one
recording-armed track.
■ CH SELECT Buttons
Use these to specify the track/bus whose EQ/send level you want to control. The selected button
will light red.
■ PAN Knobs 1–12
When CH ASSIGN is [TRACK]: Track pan
When CH ASSIGN is [AUX]: Aux bus return balance
When CH ASSIGN is [MAIN]: Virtual Main balance
