End Piece and Reflector End Cap
90° Elbow
Fasten end piece
to brackets using two
#8 sheet metal screws
and replace reflector end cap.
Insert end piece
between grille and
brackets.
End Piece
Reflector
End Cap
Descr ipti on Part Number
End Piece 01365901
Insert
End Piece
between
grille and
brackets.
Joint Piece Cut grille bracket at
reflector joint piece.
Grille Brackets
Inside
Corner
Decorative Grille
Brackets
Joint Piece
