Operation
34
MI
6 Operation
Once you have the sensor positioned and connected properly, the
system is ready for continuous operation.
The operation of the sensor can be done by means of the built‐in
control panel on the sensor’s electronic board or by means of the
software that came with your sensor optionally.
6.1 Control Panel
The sensor is equipped with a control panel in the sensor’s electronic
housing, which has setting/controlling buttons and an LCD display.
The actual function mode is shown on the display with a specific
mode symbol.
Figure 24: Control Panel
Output Jumper
Mode Symbol
Value
Mode Button
Value Buttons
