Technical Data
8
MI
3.4 Environmental Specifications
Ambient Temperature
MIH sensing head
0 to 180°C (32 to 356°F)
MIC sensing head
0 to 125°C (32 to 257°F)
MID sensing head
0 to 85°C (32 to 185°F)
MID with air cooling
‐18 to 200°C (0 to 392°F)
Electronics box
0 to 65°C (32 to 150°F)
Storage Temperature
‐10 to 85°C (14 to 185°F)
Rating (Head)
IP 65 (NEMA‐4), not for models with an
optical resolution of 2:1
Rating (Box)
IP 65 (NEMA‐4)
Relative Humidity
10% to 95% non‐condensing
EMC
IEC 61326‐1
max. cable length 3 m (118 in.)
Vibration (Head)
IEC 60068‐2‐6: 2 G, 10 to 150 Hz, 3 axes
Shock (Head)
IEC 60068‐2‐27: 50 G, 11 ms, 3 axes
Weight (Head)
50 g (2 oz.) with 1 m cable, stainless steel
Weight (Box)
270 g (10 oz.), die‐cast zinc
Head Cable Material
MID/MIC
PUR (Polyurethane), Halogen free,
Silicone free
MIH
Teflon
®
Teflon develops poisonous gasses when it comes into
contact with flames!
