Report Formats
Example 1. Error Report*
Example 2. Journal*
The Mode Column
See the bottom of the Journal for a full listing of symbols on the Journal. On
other reports a code is given, informing the type of communication. These
codes are explained below.
The Result Column
OK: Successful communication
E: An error occurred
The Footnote on the Journal
TX counter: Total number of transmitted pages
RX counter: Total number of received pages
* * * ERROR REPORT (AUG 01 1995 -06:00 ) * * *
TTI XYZ COMPANY
FILE ADDRESS MODE TIME PAGE RESULT
--------------------------------------------------------------------
Report details appear here
* * * JOURNAL (AUG 01 1995 07:00) * * *
TTI XYZ COMPANY
DATE TIME ADDRESS MODE TIME PAGE RESULT FILE
--------------------------------------------------------------------
Transmission details appear here
DATE TIME ADDRESS MODE TIME PAGE RESULT FILE
-------------------------------------------------------------------
Reception details appear here
OTHER FEATURES Verifying Communications, Errors, Counters, etc.
34
