Connecting the Machine to a Telephone Line and Telephone
43
1
Connecting the Machine to a Telephone
Line and Telephone
This section describes how to connect the machine to the telephone lines and se-
lect the line type.
Connecting the Telephone Line
To connect the machine to a telephone line, use a snap-in modular type connec-
tor.
Important
❒ Make sure the connector is the correct type before you start.
1. G3 interface unit connector 2. External telephone connector
Selecting the Line Type
Select the line type to which the machine is connected. There are two types: tone
and pulse dial.
Select the line type using “Administrator Tools”.
Note
❒ This function is not available in some regions.
Reference
p.87 “Fax Features”
AMD016S
