Connecting to the Interfaces
15
1
Checking the Signal
When using in infrastructure mode, you can check the machine's radio wave sta-
tus using the control panel.
A Select [System Settings] using {U} or {T}, and then press the {OK} key.
B Select [Interface Settings] using {U} or {T}, and then press the {OK} key.
C Select [IEEE 802.11b] using {U} or {T}, and then press the {OK} key.
D Select [Wireless LAN Signal] using {U} or {T}, and then press the {OK} key.
The machine's radio wave status appears.
E After checking radio wave status, press the {OK} key.
F Press the {User Tools/Counter} key to return to the User Tools/Counter menu.
Note
❒ To check the radio wave status, press [IEEE 802.11b] under [LAN Type] in Net-
work menu of Interface Setting.
❒ For the procedure of entering the System Settings, see “Accessing user Tools
(System Settings)”.
Reference
p.4 “Accessing User Tools (System Settings)”
p.35 “Using Utilities to Make Network Settings”
p.61 “IEEE 802.11b”
