Connecting to the ethernet interface – Ricoh Aficio ISC 615G User Manual
Page 16
Connecting the Machine
8
1
Connecting to the Ethernet Interface
Connect 10BASE-T or 100BASE-TX cable to the Ethernet interface.
Important
❒ If the main power switch is on, turn it off.
A
Loop the network interface cable and attach the ferrite core.
B
Make sure the main power switch of the machine is off.
C
Connect the Ethernet interface cable to the 10BASE-T/100BASE-TX port.
D
Connect the other end of the Ethernet cable to a network connection device
such as a hub.
AEW017S
AMB004S
