Replacing the Stamp Cartridge
135
6
Replacing the Stamp Cartridge
When the stamp becomes lighter, re-
place the cartridge.
Note
❒ This stamp cartridge is used for
facsimile and scanner functions.
❒ Use the cartridge specified for this
machine.
❒ Do not add ink to the cartridge by
yourself. Neglecting this can cause
ink leakage.
❒ Be sure not to dirty your fingers
with ink from the cartridge.
AAAA
Open the ADF unit.
BBBB
Open the stamp cover.
CCCC
Pull out the old stamp cartridge.
DDDD
Insert the new stamp cartridge.
Insert the cartridge until the metal
parts are no longer visible.
1. New Cartridge
EEEE
Replace the stamp cover until it
clicks.
FFFF
Close the ADF unit.
ZGNH010J
ZGNH011J
