Troubleshooting
118
6
- - - -Issues When Installing the Toner Cartridge
Make sure the toner cartridge is not misaligned to the left (
B). If it is, carefully
lift and move the cartridge to the right so it is located at (
A).
Important
❒ If the toner cartridge is misaligned, printing may be affected.
• 4: Hold a new cartridge and shake it 10 or
12 times.
Note
❒ Do not touch the "metal contact point"
of the cartridge, or it may be damaged.
• 5: Hold the cartridge as shown and tap it 7-
8 times against the palm of your other
hand.
• 6: Carefully remove the tape.
Important
❒ Toner spills if the shutter opens. Take
care to keep the shutter closed when re-
moving the tape.
• 7:Insert the cartridge horizontally, and
gently push it in completely.
AFT030S
AFT031S
AFT032S
AFT017S
AFT018S
