Chapter 1 5
Connections and Setup
Contents of the Package
Cinema Screen monitor
Power cord
Ferrite cores
RGB cable (Mini D-Sub 15-pin to Mini D-Sub 15- pin connector)
Remote control unit with two AA batteries
User’s manual
In order to conform to mandatory FCC standards, you must attach the supplied ferrite cores to both ends of the power cable (see
below).
If you are connecting a computer to the monitor, you must attach the ferrite cores to both ends of the DVI cable to meet FCC
standards.
Attaching the ferrite cores
Set the ferrite cores on the both ends of the DVI cable (supplied), and both ends of the power cable (supplied). Close the lid tightly
until the clamps click. Use the band (supplied) to secure the ferrite core.
core (small)
band band
core (small)
connector
DVI cable
(supplied)
(monitor side)
core (large)
power cable (supplied)
band
It is highly recommended that you have your monitor installed by a professional. If you are installing the monitor yourself,
refer to the Reference section.
NOTE: If you are planning on attaching the floor stand to your monitor (and not the optional wall mount unit) you may
want to use the safety metal fittings (provided) to give your monitor extra stability.
The safety metal fittings attach to the back of the screen and can then be used to secure the monitor to the wall with
strong wire.
Contact your trained, authorized dealer for professional installation.
Chapter 1 Connections and Setup
core (small)
band
