Connections and Setup
12 Chapter 1
The Remote Control
ANTENNA In HD RCVR mode, switches the
HD receiver between Antenna A and Antenna
B.
Arrows Use to navigate through the
menu screens and move the Zoom
pointer in Zoom mode.
AUX Operates the component you’ve
programmed to work with the AUX button.
CH+/CH– Changes channels on the HD
receiver when the remote is in HD receiver
mode. When the Zoom mode is active, zooms
in (CH+) or out (CH-).
CINEMA Select screen sizes to suit the
type of input you’re watching.
CLEAR Clears on-screen displays.
CMPNT Toggles between CMPNT1 and
CMPNT2 inputs.
GO BACK In HD receiver mode, returns you to
the previous channel. When in the menu
system, returns you to the previous menu.
OK/ZOOM In Monitor mode (using
on-screen menus), press OK to select a
highlighted item. When no menus are
displayed, press OK to bring up the
zoom pointer. Use the CH+/- buttons
to zoom in/out.
Numbers Use to make numerical entries.
MUTE Makes sound inaudible.
MONITOR Turns the monitor on and puts the
remote in Monitor mode.
GUIDE In HD receiver mode, brings
up the on-screen program guide.
INFO Brings up channel information.
INPUT Press to toggle through all
inputs (RGB, Component, Video).
MENU Brings up the on-screen menu.
STOP PAUSE
MONITOR ON•OFF
AUX DVD HD RCVR
RECORD
PLAY FORWARD REVERSE
SLEEP
WHO•MULTI MUTE
INFO
MENU
OK
CLEAR
GUIDE
ANTENNA
1 2 3
4 5 6
7 8 9
0
INPUT
VCR 1
VCR 2
CH +
CH –
V
O
L V
O
L
GO BACK
CINEMA RGB CMPNT VIDEO
ZOOM IN
ZOOM OUT
ZOOM
u n i v e r s a l
SOURCE
ZOOM IN In zoom mode enlarges the picture.
Use the arrow buttons to pan and scan the
entire picture.
WHO•MULTI When in Monitor mode,
activates the multi-screen feature. The Multi-
screen feature allows you to select a screen
mode for viewing a single picture, side-by-side
pictures, or picture-in-picture (PIP). Brings up
personal viewer profiles for some components.
VIDEO Toggles through video inputs.
VOL Adjusts the volume.
VCR1, VCR2, DVD, HD RCVR The
component buttons used to put the
remote into the correct mode to operate
that particular component. The correct
video source must first be selected or
Autotuning must be set up.
SLEEP Brings up the sleep timer, which
turns the monitor off automatically after
a set amount of time.
RGB Depending on how you set up the monitor,
toggles between RGB1, RGB2*, and RGB3.
*Note: You can set up CMPNT2 OR RGB2, but not
both. If CMPNT2 is set up, RGB2 will not appear
when you use the RGB button.
REVERSE, PLAY, FORWARD, STOP,
PAUSE, RECORD (transport keys) Use
with components programmed to work
with your remote control.
ON•OFF Toggles power on and
off for the components that you
have programmed.
