29
Chapter 2 Using the XV-5080 Effects
Chap.2
LF Damp Gain -36–0 dB
Adjusts the amount of damping applied to the frequency
range selected with LF Damp. With a setting of “0,” there
will be no reduction of the reverb’s low-frequency content.
HF Damp Freq (LF Damp Frequency) *3
Specifies the frequency above which the high-frequency
content of the reverb sound will be reduced, or “damped.”
HF Damp Gain -36–0 dB
Adjusts the amount of damping applied to the frequency
range selected with HF Damp. With a setting of “0,” there
will be no reduction of the reverb’s high-frequency content.
*1 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600,
2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12500
Hz, BYPASS
*2 50, 64, 80, 100, 125, 160, 200, 250, 320, 400, 500, 640, 800,
1000, 1250, 1600, 2000, 2500, 3200, 4000 Hz
*3 4000, 5000, 6400, 8000, 10000, 12500 Hz
