219
Chapter 10 Examples of Applications Using the XV-5080
Chap.10
PAN
TVA ENV A-TIME
TVA ENV D-TIME
TVA ENV R-TIME
Sens
Range: -63– +63
Adjusts the amount of change that will occur in response to
controller changes. Negative (-) values invert the change.
Negative (-) settings will invert the phase. For LFO rates,
negative (-) values slow down the LFO, and positive (+)
values will speed it up.
Tone
Selects the Tone to which the two previous parameter
settings are applied. “o” turns signifies that the Tone is
selected for control, “_” that it is not selected, and “R” that
the change being applied is inverted when applied to this
Tone.
Applications for Patches
Syncing the LFO Cycle to System
Tempo
1. Select the Patch you wish to synchronize on the PATCH
PLAY page.
2. Set the Patch Clock Source parameter (PATCH Common
General #2 page) to “SYSTEM.”
3. Set the beat length of the Rate (PATCH LFO&TL LFO 1, 2
page) of each Tone to match the System Tempo.
4. Set the System Clock Source parameter (SYSTEM
General #1 page) to “INT.”
* When System Clock Source is set to “MIDI,” you can
synchronize the Multi-effect to the tempo of an external MIDI
device.
5. If the System Tempo (SYSTEM General #1 page)
changes, the LFO Rate changes along with it.
6. Set the modulation depth as desired using LFO Depth
(PATCH LFO&CTL LFO 1, 2 page) for each Tone.
* Tempo synchronization is not available with Multi-Partial
Patches.
Modifying Multi-Effects to Match
the System’s Tempo
You can modify Multi-effects parameter values in time with
the System Tempo when you have selected the following
Multi-effects.
MFX Type MFX parameter
16:STEP FLANGER Step Rate
19:TRIPLE TAP DELAY Delay L-R
20:QUADRUPLE TAP DELAY Delay1-4
41:STEREO PHASER Rate,Step Rate
42:KEYSYNC FLANGER Rate,Step Rate
43:FORMANT FILTER Rate
45:MULTI TAP DELAY Delay1-4
46:REVERSE DELAY Delay1-4
47:SHUFFLE DELAY Delay
48:3D DELAY Delay Left/Right/Center
58:SLICER Rate
60:3D CHORUS Rate
61:3D FLANGER Rate,Step Rate
62:TREMOLO Rate
63:AUTO PAN Rate
