8.8 Horizontal Ventilation 4" (10 cm) Pipe

8.9 Vertical Ventilation 4" (10 cm) Pipe

Description

Part Number

Vent Terminal (Comb. Wall)

90502100

Vent Terminal

02537801-XX

Vent Cap 4" (10 cm)

90502300

Description

Part Number

Vent Cap 4" (10 cm)

90502300
