Figure 5-5 . removing the primary lens, 5. removing the primary lens, Pre l iminar y – Runco VX-44D User Manual
Page 96
Maintenance and Troubleshooting
80
Runco VX-44d/-55d Installation/Operation Manual
PRE
L
IMINAR
Y
5.
Grasping the lens barrel, turn it in a counter-clockwise direction until it stops. Then,
pull it forward to remove it (disconnects from the connector assembly).
Figure 5-5. Removing the Primary Lens
Note: The connector assembly moves as you turn the lens.
