Component Video Source Connections: Connect your component video sources to
the HD1, HD2 and/or Component/SCART inputs as shown in Figure 3-11.
Figure 3-11. Component Video Source Connections
Y P
B
P
R
COMPONEN T
VIDEO OUT
BD/DVD
DTV-Set-Top Box
(DTV-STB)
RCA-to-BNC
adapter
