Installation
Runco VX-44d/-55d Installation/Operation Manual 47
PRE
L
IMINAR
Y
Installation Menu Select Installation from the VX-44d/-55d Main Menu to access these advanced lamp
and lens configuration options:
• LumaCal™, for maintaining constant lamp brightness
• OptiCal™, to save and restore lens positions
Calibration and Test Patterns – LumaCal (Lamp Calibration): LumaCal defines the
range of power needed to maintain lamp brightness over time.
To use LumaCal:
1. Select Installation from the Main Menu.
2. Select Calibration and Test Patterns from the Installation Menu.
3. Select LumaCal from the Calibration and Test Patterns Menu.
4. Select Calibrate LumaCal to calibrate the lamp using your projector's unique
specifications (recommended). Or, select Use Default Settings to undo the effects
of a previous calibration.
In the event of a power failure, the projector reverts to the default LumaCal settings in
which case you should re-calibrate the lamp.
1. Language English
2. Picture Orientation Front
3. Reserved
4. Auto
Power Up
5. Set Date and Time
6. OSD Adjust
7. IR and Serial Adjust
8. Geometry and Color
9. Calibration and Test Patterns
0. Service Mode
Option 1 Card: Empty
Option 2 Card: Empty
Installation
1. Test Patterns Grid
2. Test Pattern Level 512
3. Freeze Image
4. Color Enable White
5. Odd Pixel Adjustment
6. Reserved
7. Clipping Detector
8. Level Detector
9. Level Value 512
0. Aspect Ratio Overlay
LumaCal Calibrate LumaCal
OptiCal Full
Automatic Lens Calibration
Calibration and Test Patterns
For best results, allow the projector to warm up for 15 minutes prior
to using LumaCal.
LumaCal lamp calibration takes approximately two minutes.
Note
Note
