Configuration and Installation Chapter 2
SCXI-1120 User Manual 2-14 © National Instruments Corporation
I
Vs
V cm
High
CMV
V out
+
-
+
-
+
-
+
Module
Figure 2-4. Ground-Referenced Signal Connection with High Common-Mode Voltage
+
I
Vs
V
out
+
-
+
-
Module
Figure 2-5. Floating Signal Connection Referenced to Chassis Ground for Better
Signal-to-Noise Ratio
I
Vs
V out
+
-
+
-
R bias
+
Module
Figure 2-6. Floating AC-Coupled Signal Connection
