Page 148
ND-45492 (E)
CHAPTER 3
Page 131
Revision 2.0
(13) Power Failure Transfer (PFT)
The PN-AUCA card or the PZ-8PFTA card can be used as the PFT card.
(a) When using PN-AUCA card
•
An outline of a PFT (PN-AUCA) connection is shown in
•
The MDF cross connection for a PFT (PN-AUCA) is shown in
Figure 007-38 Outline of the PFT (PN-AUCA) Connection
NAP 200-007
Sheet 46/56
Termination of Cables on the MDF
MDF
TEL
PN-AUCA
PBX
MDF
PN-4COT
TO C.O. LINE
