CHAPTER 3 ND-45492 (E)
Page 112
Revision 2.0
(6) SN610 ATTCON
(a) When using PN-2DLCC
Figure 007-23 MDF Cross Connection for an SN610 ATTCON (1 of 3)
NAP 200-007
Sheet 27/56
Termination of Cables on the MDF
26
27
28
29 TA0
TB0
TA1
TB1 1
2
3
4 RA0
RB0
RA1
RB1 TA0
TB0
TA1
TB1 1
2
3
4 RA0
RB0
RA1
RB1 26
27
28
29
BLACK
YELLOW
GREEN
LT00
PN-2DLCC
PIM0
LEN0000 (No. 0)
LEN0001 (No. 1)
TA0
RA0
TB0
RB0
TA1
RA1
TB1
RB1
1
26
2
27
3
28
4
29
1
26
2
27
3
28
4
29
MDF
RED
MODULAR TERMINAL
TO SN610 ATTCON
LEN0001
LEN0000
LTC0 (J) (P)
