Wireless Router Setup Manual
10 Getting to Know Your Wireless Router
v1.0, August 2007
d. Check the wireless router status lights to verify the following:
• Power. The power light (1) should turn solid green. If it does not, see “Verify whether
the Test light never turns on or stays on:” on page 21 .
• Test: The test light (2) blinks when the router is first turned on, then goes off. If after 2
minutes it is still on, see
“Verify whether the Test light never turns on or stays on:” on
page 21 .
• Wireless. The wireless light (3) should be on.
• Internet: The Internet port light (4) should be lit. If it is not, make sure that the
Ethernet cable is securely attached to the wireless router Internet port and that the
modem, and the modem is powered on.
• LAN. A LAN light (5) should be lit. Green indicates that your computer is
communicating at 100 Mbps; amber indicates 10 Mbps. If a LAN light is not lit, check
that the Ethernet cable from the computer to the router is securely attached at both
ends, and that the computer is turned on.
3. Connect to the wireless router by typing http://www.routerlogin.net in the address field of
your browser, and then click Enter.
Figure 9
Figure 10
Connect to the wireless router by typing any one of these three URLs in the address
field of your browser, then clicking Enter:
• http://www.routerlogin.net
• http://www.routerlogin.com
• http://192.168.1.1
