Wireless Router Setup Manual
8 Getting to Know Your Wireless Router
v1.0, August 2007
Connecting Your Wireless Router
To connect your wireless router:
1. Connect the wireless router, the computer, and the modem.
a. Turn off your computer.
b. Turn off and unplug the cable or ADSL broadband modem.
c. Locate the Ethernet cable (1) that connects your computer to the modem.
d. Disconnect the cable at the modem (2). You will connect it to the router later.
e. Use the label on the bottom of the wireless router to locate the Internet port, which is on
the left next to the power connection.
f. Locate the Ethernet cable that came with the NETGEAR product. Securely insert that
Ethernet cable into your modem and into the Internet port of the wireless router (3).
Figure 6
Figure 7
1
2
3
