User’s Manual U16214EJ1V0UM
5
INTRODUCTION
Product Overview The IE-780338-NS-EM1 is designed to be used with the IE-78K0-NS or IE-78K0-NS-A to
debug the following target devices that belong to the 78K/0 Series of 8-bit single-chip
microcontrollers.
• µPD780318 Subseries: µPD780316, 780318
• µPD780328 Subseries: µPD780326, 780328
• µPD780338 Subseries: µPD780336, 780338, 78F0338
Target Readers This manual is intended for engineers who will use the IE-780338-NS-EM1 with the IE-
78K0-NS or IE-78K0-NS-A to perform system debugging.
Engineers who use this manual are expected to be thoroughly familiar with the target
device’s functions and usage methods and to be knowledgeable about debugging.
Organization When using the IE-780338-NS-EM1, refer to not only this manual (supplied with the IE-
780338-NS-EM1) but also the manual that is supplied with the IE-78K0-NS or IE-78K0-
NS-A.
The IE-78K0-NS used in combination with the IE-78K0-NS-PA is functionally equivalent
to the IE-78K0-NS-A. Therefore, as necessary, read IE-78K0-NS + IE-78K0-NS-PA for
IE-78K0-NS-A in this document.
IE-78K0-NS or IE-78K0-NS-A IE-780338-NS-EM1
User’s Manual User’s Manual
• Basic specifications • General
• System configuration • Part names
• External interface functions • Installation
• Differences between target devices
and target interface circuits
• Restrictions and cautions on use
Purpose This manual is intended to give users an understanding of the various debugging
functions that can be performed when using the IE-780338-NS-EM1.
