CHAPTER 3 INSTALLATION
User’s Manual U16214EJ1V0UM
35
3.5 Jumper Settings on IE-78K0-NS
When using the IE-780338-NS-EM1 in combination with the IE-78K0-NS, set the jumper on the IE-78K0-NS as
shown below.
For details of these jumper positions, refer to the IE-78K0-NS User’s Manual (U13731E).
Caution If the jumpers are set incorrectly, the board may be damaged.
Table 3-3. Jumper Settings on IE-78K0-NS
JP2 JP3 JP4 JP6 JP7 JP8
Setting 2 to 3 shorted 1 to 2 shorted 1 to 2 shorted 3 to 4 shorted 1 to 2 shorted Note
Note The settings for the JP8 are as follows.
1-2 shorted: Internal selection of subsystem clock
3-4 shorted: External selection of subsystem clock
3.6 Jumper Settings on IE-78K0-NS-A
When using the IE-780338-NS-EM1 in combination with the IE-78K0-NS-A, set the jumper on the IE-78K0-NS-A
as shown below.
For details of these jumper positions, refer to the IE-78K0-NS-A User’s Manual (U14889E).
Caution If the jumpers are set incorrectly, the board may be damaged.
Table 3-4. Jumper Settings on IE-78K0-NS-A G-780009 Board
JP2 JP3 JP4 JP6 JP7 JP8
Setting 2 to 3 shorted 1 to 2 shorted 1 to 2 shorted 3 to 4 shorted 1 to 2 shorted Note
Note The settings for the JP8 are as follows.
1-2 shorted: Internal selection of subsystem clock
3-4 shorted: External selection of subsystem clock
Table 3-5. Jumper Settings on IE-78K0-NS-A G-78K0H Option Board
JP2
Setting 2 to 3 shorted
