APPENDIX A EMULATION PROBE PIN ASSIGNMENT TABLE

Table A-1. SWEX-120SE-1 Pin Assignments (1/2)

Emulation Probe

CN5 Pin No.

Emulation Probe

CN5 Pin No.

1

1

35

35

2

2

36

36

3

3

37

37

4

4

38

38

5

5

39

39

6

6

40

40

7

7

41

41

8

8

42

42

9

9

43

43

10

10

44

44

11

11

45

45

12

12

46

46

13

13

47

47

14

14

48

48

15

15

49

49

16

16

50

50

17

17

51

51

18

18

52

52

19

19

53

53

20

20

54

54

21

21

55

55

22

22

56

56

23

23

57

57

24

24

58

58

25

25

59

59

26

26

60

60

27

27

61

61

28

28

62

62

29

29

63

63

30

30

64

64

31

31

65

65

32

32

66

66

33

33

67

67

34

34

68

68

Remarks 1. The SWEX-120SE-1 is product of TOKYO ELETECH CORPORATION.

2. The numbers in the “Emulation Probe” column indicate the corresponding pin number on the

emulation probe tip.
