NEC uPD780328 Subseries - Manual (Page 14)

CHAPTER 1 GENERAL
User’s Manual U16214EJ1V0UM
14
1.3 Basic Specifications
The IE-780338-NS-EM1’s basic specifications are listed in Table 1-2.
Table 1-2. Basic Specifications
Parameter Description
Target device µPD780318, 780328, 780338 Subseries
System clock 10.0 MHz
Main system clock supply External: Clock input from the target system via an emulation probe
Internal: Clock mounted on the emulation board (10.0 MHz) or mounted on the parts board by
the user
Subsystem clock supply External: Input from the target system via an emulation probe
Internal: Mounted on the emulation board (32.768 kHz) or mounted on the parts board by the
user
Low voltage support V DD = 1.8 to 5.5 V (same as the target device)
