APPENDIX B DEVELOPMENT TOOLS
B.3.1 Hardware (2/2)
(2) When using in-circuit emulator IE-78001-R-A
IE-78001-R-A Note 1 The in-circuit emulator serves to debug hardware and software when
In-circuit emulator developing application systems using a 78K/0 Series product. It corresponds
to integrated debugger (ID78K0). This emulator should be used in combination
with emulation probe, and interface adapter which is required to connect this
emulator to the host machine.
IE-70000-98-IF-B or This adapter is required when using the PC-9800 Series computer (except
IE-70000-98-IF-C Note 1 notebook type) as the IE-78001-R-A host machine.
Interface adapter
IE-70000-PC-IF-B or This adapter is required when using the IBM PC/AT and their compatible
IE-70000-PC-IF-C Note 1 machine as the IE-78001-R-A host machine.
Interface adapter
IE-78000-R-SV3 This is an adapter and cable necessary when using EWS as a host
Interface adapter machine for the IE-78000-R-A.
As Ethernet™, 10Base-5 is supported. With other mode, commercially
available conversion adapter is necessary.
IE-780308-NS-EM1 Note 1 This board emulates the operations of the peripheral hardware peculiar to
Emulation board a device. It should be used in combination with an in-circuit emulator and
emulation probe conversion.
IE-78K0-R-EX1 Note 1 This board is required when using the IE-780308-NS-EM1 with the
Emulation probe IE-78001-R-A.
conversion board
IE-78064-R-EM Note 2 This is a board for emulation of peripheral hardware inherent to this device.
IE-780308-R-EM (IE-78064-R-EM is for 3.0 to 6.0 V and IE-780308-R-EM is for 2.0 to 5.0 V.)
Emulation board Use in combination with a IE-78001-R-A.
NP-EP-78230GC-R This probe is used to connect the in-circuit emulator to the target system
Emulation probe and is designed for 80-pin plastic QFP (GC-3B9, GC-8BT types).
EV-9200GC-80 This conversion socket connects the EP-78230GC-R to the target system
Conversion socket board designed to mount a 80-pin plastic QFP (GC-3B9, GC-8BT types).
(Refer to Figure B-2)
NP-EP-78054GK-R This probe is used to connect the in-circuit emulator to the target system
Emulation probe and is designed for 80-pin plastic TQFP (GK-BE9 type).
TGK-080SDW This conversion adapter connects the EP-78054GK-R to the target system
Conversion adapter board designed to mount a 80-pin plastic TQFP (GK-BE9 type).
(Refer to Figure B-3)
Notes 1. Under development
2. Maintenance product
Remarks 1. TGK-080SDW is a product of TOKYO ELETECH CORPORATION.
Inquiries : Daimaru Kougyou Co., Ltd.
Phone : (03) 3820-7112 Tokyo Electronic Component Division
(06) 244-6672 Osaka Electronic Component Division
2. EV-9200GC-80 is sold in sets of five units.
3. TGK-080SDW is sold on a unit basis.
