CHAPTER 16 SERIAL INTERFACE CHANNEL 0 (

µ

PD78058F SUBSERIES)

Notes 1. Bit 6 (COI) is a read-only bit.

2. Can be used as a port.

3. To use the wake-up function (WUP = 1), clear the bit 5 (SIC) of the interrupt timing specify

register (SINT) to 0.

4. When CSIE0 = 0, COI becomes 0.

5. In the SBI mode, the operation of serial interface channel 0 should be stopped after WUP is

cleared to “0”. If WUP is not cleared to “0”, P25 is fixed to high-level, and it may become

impossible to use it as a normal port.

Remark

×

: don’t care

PMXX : Port Mode Register

PXX

: Port Output Latch

SBI mode

6

5

4

3

2

1

0

7

Symbol

CSIM0 CSIE0 COI

WUP

CSIM04 CSIM03 CSIM02 CSIM01 CSIM00

CSIM01

0

1

Serial Interface Channel 0 Clock Selection

Input Clock to SCK0 pin from off-chip

8-bit timer register 2 (TM2) output

0

R/W

1

Clock specified with bits 0 to 3 of timer clock select register 3 (TCL3)

CSIM

04

0

1

CSIM00

×

0

1

FF60H 00H R/W

Note 1

Address After Reset R/W

R/W

CSIM

03

CSIM

02

PM25 P25 PM26 P26 PM27 P27

Operation

Mode

Start Bit

SI0/SB0/P25

Pin Function

SO0/SB1/P26

Pin Function

SCK0/P27

Pin Function

Ч

1

0

Ч

0

Ч

0

0

Ч

0

Ч

0

0

1

1

Note 2 Note 2

Note 2 Note 2

MSB

P25 (CMOS

input/output)

SB0 (N-ch

open-drain

input/output)

SB1 (N-ch

open-drain

input/output)

P26 (CMOS

input/output)

WUP

0

1

Wake-up Function Control

Note 3

Interrupt request signal generation with each serial transfer in any mode

Interrupt request signal generation when the address received after bus release
(when CMDD = RELD = 1) matches the slave address register (SVA) data in SBI mode

R/W

1

1

3-wired serial I/O mode (16.4.2, 3-wire serial I/O mode operation.)

2-wired serial I/O mode (see section 16.4.4, 2-wire serial I/O mode operation.)

SCK0 (CMOS

input/output)

COI

0

Slave Address Comparison Result Flag

Note 4

Slave address register (SVA) not equal to serial I/O shift register (SIO0) 0 data

Slave address register (SVA) equal to serial I/O shift register (SIO0) 0 data

R

1

CSIE0

0

Serial Interface Channel 0 Operation Control

Note 5

Operation stopped

Operation enabled

R/W

1
