224
CHAPTER 9 8-BIT TIMER/EVENT COUNTERS
0 1 2 3 4 5 6 7 Symbol
PM30 FF23H FFH R/W
Address After Reset R/W
PM31 PM32 PM33 PM34 PM35 PM36 PM37 PM3
PM3n P3n Pin Input/Output Mode Selection (n=0 to 7)
0 Output mode (output buffer ON)
1 Input mode (output buffer OFF)
(4) Port mode register 3 (PM3)
This register sets port 3 input/output in 1-bit units.
When using the P31/TO1 and P32/TO2 pins for timer output, set PM31, PM32, and output latches of P31 and
P32 to 0.
PM3 is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets PM3 to FFH.
Figure 9-7. Port Mode Register 3 Format
