CHAPTER 9 8-BIT TIMER/EVENT COUNTERS
9.2 8-Bit Timer/Event Counter Configuration
The 8-bit timer/event counters 1 and 2 consist of the following hardware.
Table 9-5. 8-Bit Timer/Event Counter Configuration
Item
Configuration
Timer register
8 bits
×
2 (TM1, TM2)
Register
Compare register: 8 bits
×
2 (CR10, CR20)
Timer output
2 (TO1, TO2)
Timer clock select register 1 (TCL1)
8-bit timer mode control register 1 (TMC1)
8-bit timer output control register (TOC1)
Port mode register 3 (PM3)
Note
Control register
Note See Figure 6-9 P30 to P37 Block Diagram.
