Chapter 1
DAQ System Overview
© National Instruments Corporation
1-7
•
SCXI modules and accessories for isolating, amplifying, exciting, and
multiplexing signals for relays and analog output; with SCXI you can
condition and acquire up to 3,072 channels
•
Low-channel-count signal conditioning modules, devices, and
accessories, including conditioning for strain gauges and RTDs,
simultaneous sample-and-hold circuitry, and relays
For more specific information about these products, refer to
ni.com
.
Using Accessories with Devices
Complete the following steps to choose a cable to connect an E Series
device and an accessory:
1.
Select an E Series device.
2.
Using Table 1-1 or Table 1-2 as a guide, determine which accessories
are appropriate for that device. Select an accessory. Table 1-3 provides
descriptions for E Series device accessories.
3.
Using Table 1-1 or Table 1-2 as a guide, determine which cable is
required to connect your selected device and accessory.
Table 1-1. 68-Pin and DAQCard E Series Accessories and Recommended Cables
Device
Acessories and Recommended Cables
TBX-68, CB-68LP,
CB-68LPR, DAQ Signal
Accessory, CA-1000,
BNC-2110, BNC-2111,
BNC-2120, BNC-2090,
SCB-68
TB-2705
68-pin E Series
(except DAQCard)
SH6868EP (shielded)
R6868 (unshielded)
Connects directly to the device
(PXI only
)
E Series DAQCards:
NI 6024E, NI 6036E,
NI 6062E
SHC6868EP/M (shielded)
RC6868 (unshielded
)
—
