Ni 6031e pinout – National Instruments Data Acquisition Device E Series User Manual
Page 184
Appendix A
Device-Specific Information
© National Instruments Corporation
A-49
NI 6031E Pinout
Figure A-44 shows the NI 6031E device pinout.
Note
Some hardware accessories may not yet reflect the NI-DAQmx terminal names. If
you are using an E Series device in Traditional NI-DAQ (Legacy), refer to Table 1-5,
, for the Traditional NI-DAQ (Legacy) signal names.
