Appendix D Register-Level Programming
PC-LPM-16/PnP User Manual D-6  National Instruments Corporation
Command Register 1
(Continued)
If SCANEN* is cleared, analog channels MA<3..0>
through channel 0 are sampled. Sampling order,
whether from channel 0 to MA<3..0> or from
MA<3..0> to channel 0, is determined by the
SCANORDER bit in Command Register 2. If
SCANEN* is set, a single analog channel specified by
MA<3..0> is sampled during the entire data
acquisition operation. See the
Programming Multiple
A/D Conversions with Channel Scanning section later
in this appendix for the correct sequence involved in
setting the SCANEN* bit.
MA<3..0> Selected Channel
0100 4
0101 5
0110 6
0111 7
1000 8
1001 9
1010 10
1011 11
1100 12
1101 13
1110 14
1111 15
