 National Instruments Corporation A-1 PC-LPM-16/PnP User Manual
Specifications
Appendix
A
This appendix lists the PC-LPM-16PnP specifications. These
specifications are typical at 25
°
C unless otherwise specified. The
operating temperature range is 0
°
to 70
°
C.
PC-LPM-16PnP Board
Analog Input
Input Characteristics
Number of channels ........................... 16 single-ended
Type of ADC...................................... Successive approximation
Resolution .......................................... 12 bits, 1 in 4,096
Max sampling rate .............................. 50 kS/s
Input signal ranges .............................
±
5 V,
±
2.5 V, 0 to 10 V, or
0 to 5 V, software-selectable
Input coupling .................................... DC
Overvoltage protection .......................
±
45 V powered on,
±
35 V powered off
Inputs protected ....................... ACH<0..15>
FIFO buffer size ................................. 256 S
Data transfers ..................................... Interrupts, programmed I/O
Transfer Characteristics
Relative accuracy ..............................
±
1.0 LSB typ,
±
1.5 LSB max
Integral nonlinearity ...........................
±
0.5 LSB max
Differential nonlinearity .....................
±
1.0 LSB max
(For more information on nonlinearity and quantization error, see
the Explanation of Analog Input Specifications section)
Offset error after calibration ...............
±
1.0 LSB typ,
±
2.0 LSB max
