Appendix C Using Your PC-LPM-16 (Non-PnP) Board
 National Instruments Corporation C-3 PC-LPM-16/PnP User Manual
To determine which PC-LPM-16 board you have, refer to the Assembly
Number row in Table C-1 and compare it to the assembly number
displayed on your circuit board (see Figure C-1).
Interrupt Enable/
Disable Control Through Command
Register 1 Through Command
Register 1 Through Plug and
Play BIOS or
NI-DAQ
Configuration Utility
Delay Between Rising
EXTCONV* Edge
and A/D Conversion 2–4
µ
s 800 ns max 800 ns max
Table C-1. Comparison of Characteristics (Continued)
Functional Changes Legacy PC-LPM-16 Revised PC-LPM-16 PC-LPM-16PnP
