Appendix A Specifications
 National Instruments Corporation A-3 PC-LPM-16/PnP User Manual
Timing I/O
Number of channels ........................... 3 counter/timers (1 dedicated to
analog input)
Resolution .......................................... 16 bits
Compatibility ..................................... TTL, gate and source pulled
high with 4.7 k
Ω
resistors
Input logic low voltage....................... 0.8 V max
Input logic high voltage...................... 2.2 V min
Output logic low voltage
at output current = 4.0 mA ................. 0.45 V max
Output logic high voltage
at output current = -1.0 mA ................ 3.7 V min
Base clocks available ......................... 1 MHz
±
0.01%
Max source frequency ........................ 8 MHz
Min source pulse duration .................. 60 ns
Min gate pulse duration ...................... 50 ns
Data transfers ..................................... Programmed I/O
Digital logic levels ............... Level Minimum Maximum
Input low voltage 0 V 0.8 V
Input high voltage 2 V 5.0 V
Input low current
(Vin = 0 V) —
±
10
µ
A
Input high current
(Vin = 5 V) —
±
10
µ
A
Level Minimum Maximum
Output low voltage
(Iout = 4 mA) — 0.4 V
Output high voltage
(Iout = 4 mA) 3.7 V —
