AJ9 (J9)
2. Screw mounting type
15
29
19
0.8
1.75 dia.
4.4
30 °
33
0.8
9.7
6.35
11
7.5 4
34
19.9
15
1.2
7
10
12.4
50
42 ±0.2
OFF ON
2-pole 1-pole
Remark: For soldering compatible with .250 Quick-connect terminal and PC board terminal, only terminal shape is changed.
mm General tolerance: ±0.5
2) Soldering compatible with .250 Quick-connect terminal
6.35
R1.5
R0.9
34
11
1
4.4
9.7
Remark: Dimensions other than listed above are same as those of .250 Quick-connect terminal.
3) PC board terminal
PC board pattern (ON-ON)
34
11
3
6
3.5 1.2 ±0.1
1.2 ±0.1
4.5 ±0.1
4.5 ±0.1
7
11 11
11 11
2-pole 1-pole
Remark: Dimensions other than listed above are same as those of .250 Quick-connect terminal.
