AJ9 (J9)
(2) With indication on actuators
(Standard flange color is black. For other colors type, they are custom ordered.)
Remarks: 1. A letter indicating the actuator color is entered in place of
∗ symbol. (W: White B: Black R: Red Z: Dark gray H: Light gray L: Blue G: Green Y: Yellow)
For requests of other flange color, please suffix following letter. (W: White R: Red Z: Dark gray H: Light gray L: Blue G: Green Y: Yellow)
2. The color of I O indication on the actuator:
White actuator: black, Others: white
3. The ON-OFF type with no indications on the actuator have received UL and CSA certifications.
All other types come with a stamp indicating international standards without your request.
2. Screw mounting type
(1) Without indication on actuators
(2) With indication on actuators
Remarks: 1. A letter indicating the actuator color is entered in place of ∗ symbol. (W: White B: Black R: Red Z: Dark gray H: Light gray L: Blue G: Green Y: Yellow)
2. The color of I O indication on the actuator:
White actuator: black, Others: white
3. The ON-OFF type with no indications on the actuator have received UL and CSA certifications.
All other types come with a stamp indicating international standards without your request.
Terminal shape Poles Operating types
Part No.
(With I O indication)
Part No.
(With — O indication)
.250 Quick-connect terminal
1-pole
ON-OFF AJ911001 ∗3F AJ911002 ∗3F
ON-ON AJ911101 ∗3F AJ911102 ∗3F
2-pole
ON-OFF AJ921001 ∗3F AJ921002 ∗3F
ON-ON AJ921101 ∗3F AJ921102 ∗3F
Soldering compatible with
.250 Quick-connect terminal
1-pole
ON-OFF AJ911011 ∗3F AJ911012 ∗3F
ON-ON AJ911111 ∗3F AJ911112 ∗3F
2-pole
ON-OFF AJ921011 ∗3F AJ921012 ∗3F
ON-ON AJ921111 ∗3F AJ921112 ∗3F
PC board terminal
1-pole
ON-OFF AJ911021 ∗3F AJ911022 ∗3F
ON-ON AJ911121 ∗3F AJ911122 ∗3F
2-pole
ON-OFF AJ921021 ∗3F AJ921022 ∗3F
ON-ON AJ921121 ∗3F AJ921122 ∗3F
Terminal shape Poles Operating types
Part number
(Without indication)
.250 Quick-connect terminal
1-pole
ON-OFF AJ912000 ∗9F
ON-ON AJ912100 ∗3F
2-pole
ON-OFF AJ922000 ∗9F
ON-ON AJ922100 ∗3F
Soldering compatible with
.250 Quick-connect terminal
1-pole
ON-OFF AJ912010 ∗9F
ON-ON AJ912110 ∗3F
2-pole
ON-OFF AJ922010 ∗9F
ON-ON AJ922110 ∗3F
PC board terminal
1-pole
ON-OFF AJ912020 ∗9F
ON-ON AJ912120 ∗3F
2-pole
ON-OFF AJ922020 ∗9F
ON-ON AJ922120 ∗3F
Terminal shape Poles Operating types
Part No.
(With I O indication)
Part No.
(With — O indication)
.250 Quick-connect terminal
1-pole
ON-OFF AJ912001 ∗3F AJ912002 ∗3F
ON-ON AJ912101 ∗3F AJ912102 ∗3F
2-pole
ON-OFF AJ922001 ∗3F AJ922002 ∗3F
ON-ON AJ922101 ∗3F AJ922102 ∗3F
Soldering compatible with
.250 Quick-connect terminal
1-pole
ON-OFF AJ912011 ∗3F AJ912012 ∗3F
ON-ON AJ912111 ∗3F AJ912112 ∗3F
2-pole
ON-OFF AJ922011 ∗3F AJ922012 ∗3F
ON-ON AJ922111 ∗3F AJ922112 ∗3F
PC board terminal
1-pole
ON-OFF AJ912021 ∗3F AJ912022 ∗3F
ON-ON AJ912121 ∗3F AJ912122 ∗3F
2-pole
ON-OFF AJ922021 ∗3F AJ922022 ∗3F
ON-ON AJ922121 ∗3F AJ922122 ∗3F
