CHECK
TEMP
AUT AUTO
ON
OFF
AUT AUTO HEA HEAT DRY FAN
C
COOL COOL
FAN AN
AUT AUTO
RESET CLOCK
MODE POWERFUL ECONOMY
FAN SPEED
AIR SWING
OFF CANCEL
ON SET
1 2 3
TIMER
OFF/ON QUIET
AUTO MANUAL
#
!
$
%
^
$
*
&
3
5
8
7
9
0
6
4
(
2
1
NAME OF EACH PART
■ Remote Control
● Remote Control Signal
• Make sure it is not obstructed.
• Maximum distance : 10 m (32.8 ft).
• Signal received sound.
One short beep or one long beep.
● Notes for Remote Control
• Do not throw or drop.
• Do not get it wet.
• Certain types of fluorescent lamps may affect
signal reception. Consult your dealer.
● How to Insert the Batteries
1
Slide down the remote control cover completely
2 Insert the batteries
– Be sure the polarities are correct
– 12:00 on display - flashing
• Set the current time (CLOCK) immediately to
prevent battery exhaustion.
● About the batteries
• Can be used for approximately one year.
● Observe the following when replacing the
batteries :
• Replace with new batteries of the same type.
• Do not use rechargeable batteries (Ni-Cd).
• Remove the batteries if the unit is not going to be
used for a long period of time.
1 Signal Transmitter
2 Operation Display
3 Quiet Mode Operation Button
4 Room Temperature Setting Button
(Illuminating button)
5 Operation Mode Selection Button
6 Economy Mode Operation Button
7 Auto Airflow Direction Button
8 ON-Timer Button
9 OFF-Timer Button
0 Reset Point
(Press with fine-tipped object to clear the memory)
! OFF/ON Button
(Illuminating button)
@ Powerful Mode Operation Button
# Fan Speed Selection Button
$ Manual Airflow Direction Button
% Timer Set Button
^ Timer Cancellation Button
& Time-Setting Button
* Clock Button
( Remote Control Cover
CH EC K
AU TO
OF
AU TO HEA T
DR Y FA N
COOL
FA N
AU TO
AU TO
RE SE T CLO CK
AIR SW IN G
OF F
CAN CEL
1
2
3 TIM ER
POW ERF UL
AU TO
MA NU AL
ECO NOM Y SLE ON
SE T
FAN SPE ED
MO DE
2
1
1.5
V 1.5
V
PREPARATION BEFORE OPERATION
■ Indoor Unit
1 Open the front panel
2 Remove the air filters
3 Fit the air purifying filters in place
4 Insert the air filters
5 Close the front panel
■ Remote Control – To set the current time
1 Press 1 .
2 Then press 2 to increase or decrease the time.
3 Press 1 again.
Set time will light up on display.
CHECK
AUTO
AUTO HEAT DRY FAN COOL
FAN
AUTO
RESET CLOCK
FAN SPEED
AIR SWING
OFF CANCEL
ON SET
1 2 3
TIMER
1
2
AUTO MANUAL
5
1
3 4
2
HOW TO OPERATE
■ To start the operation
• Press
1 .
• POWER indicator (green) on the indoor unit will light
up.
• To stop, press once more.
■ Setting Mode
• Press
2 to select:-
Cooling Model
AUTO – Automatic Operation
COOL – Cooling Operation
DRY – Soft Dry Operation
(Dehumidifying Operation)
FAN – Air Circulation Operation
Heat Pump Model
AUTO – Automatic Operation
HEAT – Heating Operation
COOL – Cooling Operation
DRY – Soft Dry Operation
(Dehumidifying Operation)
Cooling Model
COOL –> 26°C ~ 28°C
DRY
–> 1°C ~ 2°C
lower than the
room temperature
Heat Pump Model
COOL –> 26°C ~ 28°C
DRY
–> 1°C ~ 2°C
lower than the
room temperature
HEAT –> 20°C ~ 24°C
Indoor
temperature
23°C
Operation
Cooling
Soft Dry
Standard
temperature
25°C
22°C
OFF
ON
HE A HEA T
DR DR Y F AN AN
CO OL COOL
CH EC K
TE M P
AU T AUT O
AU T AUT O FA N AN
AU T AUT O
RE SE T CLO CK
AIR S W IN G
OF F
CAN CEL
1
2
3 TIM ER
OF F/O N
QU IET
ECO NOM Y POW ERF UL
ON
SE T
FAN SPE ED
MOD
E
2
3
5
1
6
4
AU TO
MA NU AL
■ Setting Temperature
• Press 3 to increase or decrease the temperature.
• The temperature can be set between 16°C ~ 30°C.
• Recommended temperature :
• During AUTO Operation, press 3 to select:
• Operation with 2°C higher than the standard
temperature.
• Operation with the standard temperature.
• Operation with 2°C lower than the standard
temperature.
● Standard Temperature
Cooling Model
• Once the Automatic Operation is selected, the indoor
temperature sensor operates automatically to select
the desired operation mode with Cooling or Soft Dry.
• After the operation mode has been selected, the
mode does not change.
Heat Pump Model
• At the beginning of the automatic operation, Heating,
Cooling or Soft Dry is automatically selected according
to the indoor temperature.
• The operation mode changes every hour, when
necessary.
Indoor
temperature
23°C
20°C
Operation
Cooling
Soft Dry
Heating
Standard
temperature
25°C
22°C
21°C
41
CS-A9CKPG CU-A9CKP6G / CS-A12CKPG CU-A12CKP6G
