Before You Start
Part names
Front side view
Front panel (See page 27 .)
Right side door
(See
pages 32 and 165 .)
Output tray
(See
page 30 .)
Fuser (See pages 150 and 158 .)
Color imaging unit (See pages 29 and 149 .)
Front door (See page 29 .)
Media tray
(See
page 33 .)
Rear side view
Multi-purpose tray (MPT)
(See
page 43 .)
Left side door
(See
page 39 .)
[Media thickness switch*
(See
page 39 .)]
*Accessible by opening the
left side door
Parallel interface
connector
(See
page 36 .)
AC inlet
(See
page 36 .)
Power switch
(See
page 37 .)
Slot cover for optional Network card (See page 203 .)
