Reproducing the time code/user bit – Panasonic AJ-HD150FE User Manual
Page 99

– 99 –
Reproducing the time code/user bit
1
Place the unit in the stop mode.
2
Set the TC/CTL button to TC.
3
Set the TC/UB switch to TC or UB.
TC: The time code is displayed.
UB: The user bit is displayed.
•
When it is no longer possible to read the time code, it is interpolated using the CTL
signal.
4
Press the PLAY button.
Playback now commences, and the time code appears on the display.
When setup menu No. 005 (SUPER) is ON, the time code value is superimposed onto
the video signal from the VIDEO OUT3 connector.
•
The colon between the seconds and frames changes to a period when the drop frame time
code is read.
•
When the time code signal is missing, it is automatically compensated for using the CTL
signal.
